Features
- Choose from five thermal color options
- Adjust display brightness for different lighting conditions
- Features auto-switch-off for energy conservation
- Configure emissivity settings (0.01 to 1.00) for various object types, such as uneven surfaces (e = 0.95), semi-matte (e = 0.85), semi-gloss (e = 0.60), and glossy (e = 0.3)
- Provides real-time temperature output
- Displays both highest and lowest temperatures
- Measures temperature in the range of -4 °F to 3632 °F (- 20 °C to 2000 °C)
Technical Specifications
| Display | 3.5 in (88.9 mm) full view TFT |
| Focus length | 0.51 in (13 mm) |
| Sensitivity | ≤ 60 mk @ 77 °F (25 °C) |
| IR temperature measurement | IR focal plane |
| Spectrum | 8 µm to 14µm |
| Frame rate | 25 Hz (50 Hz optional) |
| Temperature calibration | Automatic, manually |
| Temperature output | Real time |
| Thermal color | Rainbow, Iron, cold, white hot, black hot |
| Image intensification | Detailed setting |
| Calibration | shutter |
| Document | JPG |
| Setting | Auto-switch off, date and time, language |
| Battery | Built-in lithium battery |
| Protection | IP67 |
| Range | -4 °F to 752 °F (- 20 °C to 400 °C) |
| Temperature accuracy | ± 2% or ± 3.6 °F (± 2 °C) |
| Working temperature | 32 °F to 113 °F (0 °C to 45 °C) |
| Storage temperature | – 4 °F to 140 °F (- 20 °C to 60 °C) |
| Measured temperature | – 4 °F to 1022 °F (- 20 °C to 550 °C) |
| Dimension | 10.07 in x 3.82 in x 5.07 in (256 mm × 97.2 mm × 128.9 mm) |
| Weight | 21.16 oz (600 g) |
