Technical Specifications
| Turbidity | 0 NTU to 4000 NTU |
| Meter display size | 5.67 in x 3.39 in (15.4 cm x 86 mm) |
| pH | 0 pH to 14 pH |
| Conductivity | 1 to 200000 μS/cm |
| Communication protocol | RS 485 |
| Customized support | OEM, ODM, OBM |
| Signal Output | RS 485 Modbus |
| Measuring Range | Oxygen content: 0.00 mg/L to 20.00 mg/L |
| Saturation: 0% to 200% | |
| Temperature: 32 °F to 122 °F (0 °C to 50 °C) | |
| Accuracy | Oxygen content: ±0.1 mg/L Saturation: ±1 % Temperature: ±32.9 °F (±0.5 °C) |
| Response time | 0->100%; T90 < 25 s. 100->0%; T90< 30 s. |
| Temperature compensation | Automatic, built-in temperature unit |
| Related compensation | Salinity compensation, pressure compensation |
| Calibration method | Zero calibration and full-scale calibration |
| Working pressure | 0 Bar to 3 Bar |
| Operating temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Connection | M16 |
| Power supply | 6 V DC to 12 V DC |
| Dimensions | Diameter 1.38 in (35 mm), Total length 9.84 in (25 cm) |
| Installation dimension | A British 1 NPT of the head and the tail for each install thread; |
| Protection grade | IP68 |
| Meter working temperature | 32 °F to 140° F (0 °C to 60 °C), 0% to 96 % RH |
| Weight | 0.57 lb. (260 g) |
