Features
- Two modes: Pulse-Echo for flaw detection, and Echo-Echo for measuring without interference from paint or coating.
- Utilizing cutting-edge, high-performance, and low-power microprocessor technology.
- Automatic memory material code and sound velocity value, convenient to use.
- Use USB/RS-232 data output to connect with the PC.
- Provide Bluetooth data output choice.
Technical Specifications
| Display | LCD with backlight |
| Range | Pulse-Echo mode: (0.04 in to 11.81 in) (1.0 mm to 300 mm) (in Steel) Echo-Echo mode: (0.12 in to 1.18 in) (3 mm to 30 mm) |
| Resolution | 0.001 in / 0.1 mm / 0.01 mm |
| Accuracy | ±(0.5%n + 0.05), depending on materials and conditions |
| Measurement Period | 4 times per second for single point mode and 10 times per second for scan mode |
| Sound Velocity | 1000 m/s to 9999 m/s |
| Memory for up to 20 files (99 values for each file) of stored values | |
| Working Mode | There are two working modes of thickness measurement: single mode and scan mode |
| Operating Conditions | Temperature:32 °F to 104 °F (0 °C to 40 °C) Humidity:<85 % RH |
| Power Supply | 4 V x 1.5 V AAA(UM-4) Battery |
| Dimensions | 5.6 in x 2.83 in x 1.34 in (142 mm x 72 mm x 34 mm) |
| Weight | 0.39 lb. (175 g) (Not Including Batteries) |
| Standard Accessories | Main Unit Standard Probe Coupling Agent Carrying Case(B04) Operation Manual |
| Optional Accessories | Other Special-purpose Probe RS-232C Data Cable with Software Bluetooth Data Adapter with Software |
| Unit System | Metric system or British system (optional) |
| Display | LCD with backlight |
| Range | Pulse-Echo mode: (0.03 in to 23.62 in) (0.65 mm to 600 mm) (in Steel) Echo-Echo mode: (0.12 in to 2.36 in) (3 mm to 60 mm) |
| Resolution | 0.001 in / 0.1 mm / 0.01 mm |
| Accuracy | ±(0.5 % n + 0.05), depends on materials and conditions |
| Measurement Period | 4 times per second for single point mode and 10 times per second for scan mode |
| Sound Velocity | 1000 m/s to 9999 m/s |
| Memory for up to 20 files (99 values for each file) of stored values | |
| Working Mode | There are two working modes of thickness measurement: single mode and scan mode |
| Operating Conditions | Temperature:32 °F to 104 °F (0 °C to 40 °C) Humidity:<85%RH |
| Power Supply | 4 V x 1.5 V AAA(UM-4) Battery |
| Dimensions | 5.59 in x 2.83 in x 1.34 in (142 mm x 72 mm x 34 mm) |
| Weight | 0.39 lbs (175 g) (Not Including Batteries) |
