Features
- Smart sensors, flexible change, most can detect six kinds of gas at the same time
- Pump suction sampling, sampling distance of more than 10 meters
- Six gases at the same time display, single display,
- Curve of three kinds of interface can be switched
- 5 -inch colour LCD screen, display in both English and Chinese
- The gas concentration unit support PPM, PPB, PPH, VOL %, % LEL, mg/m3, ug/m3
- Built-in water dust filter
- Temperature compensation function to ensure accuracy of measurement
- Gas path blockage detection alarm, effectively protect the getter pump and sensors
- Fall alarm function, prevention workers poisoning faint signal alarm calls
- Support Bluetooth communication, optional Bluetooth printer
- Computer export data, check the curve
- Modular battery, can replace the battery,
- External physical interface only charging interface
- Calibration time remind of sensor and sensor life remind
- Bulk data recording
Technical specifications
| Detection Gas | Can accurately detect six kinds of gases such as O3, NH3, H2S, O2 etc |
| Battery Capacity | 7500 mAh lithium battery, nominal voltage: 3.7 V DC |
| Power Consumption | < 3 W |
| Working Time | 10 hours Response time: T90 < 30 S |
| Charging Time | ≤ 12 hours |
| Data Storage | The standard capacity of 80,000 pieces of data supports the machine to view, delete or data export, support the upper computer to export data |
| Detection Principle | Catalytic combustion, infrared detection, electrochemistry, photo ion, PID, thermal conductivity |
| Accuracy | ≤ ± 3 % F.S |
| Main Material | ABS + PC |
| Protection Class | IP54 |
| Pressure Range | 12.47 psi to 15.36 psi. (86 kPa to 106 kPa) |
| Humidity Range | 10 % RH to 95 % RH (no condensation) |
| Temperature Range | – 4 ℉ to 122 ℉ (- 20 ℃ to 50 ℃) |
| Size | 8.12 in x 2.75 in x 1.41 in (20.65 cm x 7 cm x 3.6 cm |
| Weight | 9.81 oz (280 g) |
