Features
- 15.6-inch (396 mm) TFT color display
- Capacitive (multi-touch) touchscreen
- High Definition (1,920 x 1,080) resolution
- 4-digit AC RMS, DC, and DC + AC RMS voltage measurements
- 100 MHz waveform generation
- Advanced Jitter and Eye Diagram Analysis
- User-defined filtering
- Advanced Spectrum View
- RF vs. Time traces, triggers, Spectrograms, and IQ capture
- Digital Power Management
- Mask or Limit Testing
- Inverters, Motors, and Drives
- LVDS Debug and Analysis
- PAM3 Analysis
- Advanced Power Measurements and Analysis
- Advanced Vector Signal Analysis (Signal Vu-PC)
Technical Specifications
| Bandwidth | 350 MHz to 2 GHz |
| Sampling Rate | 6.25 GS per s |
| ADC | 12 Bit |
| Input Coupling | DC or AC |
| Connectivity | USB 2.0 |
| Display | 15.6-Inch (396 mm) TFT Color |
| Dimensions | 12.2 in x 17.9 in x 8.0 in (309 mm x 454 mm x 204 mm) |
| Weight | 25.13 Ib (11.4 Kg) |
