| Analog Bandwidth |
300 MHz, 200 MHz, 100 MHz, 80 MHz/60 MHz |
| Real-time sampling |
2 GSa/s |
| Record length |
64 K |
| Time base range |
2 ns/div to 40 s/div |
| Delay between channels |
500 ps |
| Vertical system AD converter |
8-bit resolution, simultaneous acquisition of two channels |
| Vertical sensitivity |
2 mV/div to 5 V/div (at BNC input) |
| Vertical displacement range |
Various ranges |
| Rise time at BNC |
Model-specific |
| DC Gain Accuracy |
Varies according to voltage range |
| Trigger sensitivity, range, and accuracy |
Specific to models |
| Holdoff range |
100 ns to 10 s |
| Trigger type |
Video, edge, pulse width, slope, timeout, alternate trigger |
| Trigger Frequency Counter |
Provided |
| Measurement modes |
Cursor, automatic (32 types) |
| Display type |
7 in (177.8 mm) TFT 16-bit true color LCD screen |
| Display resolution |
800 x 480 |
| Connector |
USB master-slave interface |
| Power voltage |
100-120 VAC RMS (±10%), 45Hz to 440Hz, CAT II; 120-240 VAC RMS (±10%), 45Hz to 66Hz, CAT II |
| Power consumption |
< 30 W |
| Fuse |
2 A.T, 250 V |
| Size (L×W×H) |
12.32 in × 4.25 in × 5.59 in (313 mm × 108 mm × 142 mm) |
| Weight (without package) |
4.58 lb (2.08 kg) |
