Features
- 2 in 1 (DSO LA)
- 8 in (20.32 cm) LCD color display
- Support USB for data transmission to PC
- USB Flash Disk Storage
- 20 Automatic measurements
- Slope trigger and pulse trigger added
Technical Specification
| Rise Time | ≤3.5 ns |
| Channels | 2+1 (external) |
| Max. Input Voltage | 400 V |
| Vertical Sensitivity | 2 mV/div to 10 V/div |
| Display | 8 in (20.32 cm) |
| DC Gain Accuracy | ±3% |
| Waveform Storage | 4 waveforms |
| Bandwidth | 100 MHz |
| Phase Difference | ±3 degrees |
