Features
- Intelligent power management
- GPS + WIFI + LBS multimode precise positioning
- Electronic fence, safety range
- SOS calling
- History route playback.
Technical Specifications
| Chip | MTK MT2503D |
| GPRS | Class 12 |
| GPS single | L1, 1575.42 MHz C/A |
| Number of GPS channels | 22 channels |
| GPS tracking sensitivity | 165 dBm |
| Capture sensitivity | 148 dBm |
| GPS positioning accuracy | 196.85 in to 590.55 in (5000 mm to 15000 mm) |
| LBS location accuracy | 3937.00 in to 39370.07 in (100,000 mm to 10,00,000 mm) |
| GSM antenna | FPC antenna; GSM 850 MHz / 900 MHz / 1800 MHz / 1900 MHz |
| Average standby current | <2.5 mA |
| Operating temperature | <55 mA |
| Operating temperature | -4 oF to 158 oF (-20 oC to 70 oC) |
| Working humidity | 5% RH to 95% RH, not solidified |
| Certification and patent | Can approval by FCC, CE, and ROSH |
| Gravity sensor | Support |
| Bluetooth | Bluetooth 3.0 (Normal closed) |
| Size | 1.81 in x 1.26 in x 0.59 in (46 mm x 32 mm x 15 mm) |
| Weight | 0.06 lb (29 g) |
