Features
- Static MPPT reach over 99 % energy conversion
- Pure sine wave inverter
- Inverter built in wifi and Bluetooth
- Plug and play design for both villas and balconies micro inverter
- 400 W 600 W rated output power optional
Technical Specifications
| Commonly Used Module Power (W) | 200 w to 430 W |
| Maximum Input Voltage (V) | 60 |
| MPPT Voltage Range (V) | 22 to 55 |
| Input Working Voltage Rang (V) | 16 to 60 |
| Maximum Input Current (A) | 14 A |
| Number Of MPPTs | 1 |
| Number Of Inputs Per MPPT | 1 |
| Rated Output Power (W) | 400 |
| Rated Output Current (A) | 1.74 |
| Nominal Output Voltage/Range (V) | 230 |
| Nominal Frequency/Range (Hz) | 50 or 60 |
| Adjustable Power Factor | Over 0.99 |
| Total Harmonic Distortion | Less than 5 % |
| Peak Efficiency | 96.5 % |
| Nominal MPPT Efficiency | Over 99.5 % |
| Ambient Temperature Range (℃) | – 40 °F to 149 °F (- 40 ℃ to 65 ℃) |
| Interface | LED and App |
| Cooling | Natural cooling |
| Topology | Galvanically Isolated HF Transformer |
| Protection Degree | IP 67 |
| Size | 7.13 in x 7.6 in x 1.52 in (18.1 cm x 19.3 cm x 3.85 cm) |
| Weight | 5.6 lb (2.54 kg) |
