Features
- Easy maintenance
- Stable measurement
- Fully functional
- Data assurance
Technical Specification
| Range | 0 mg/L to 20 mg/L |
| Air Saturation | 0% to 200% |
| Resolution | 0.01 mg/L, 0.01 ppm |
| Accuracy | ±2% or ±0.15 mg/L |
| Sensitivity | ±0.5 mg/L |
| Maximum Load | 750 Ω |
| AC Powered | 85 V AC ± 265 V AC, 50 Hz or 60 Hz |
| DC Powered | 24 VDC ± 10% |
| Work Pressure | Up to 4 bar |
| Transmitter Operating Temperature | -4° F to 140° F (-20 ℃ to 60 ℃) |
| Sensor Operating Temperature | 32℉ to 140° F (0℃ to 60 ℃) |
| Relative Humidity | 0% to 95% RH |
| Dimensions | 6.69 in x 7.16 in x 2.95 in (170 mm x 182 mm x 75 mm) |
| Weight | 11.02 lb (5 kg) |
