Overview
Hospitality Enviro Tech Marble Surface Gloss Tester meter features with 60° angle, it is also compatible with international standards of ASTM D523, ASTM D2457. HG268 conforms to JJG696 first class gloss meter working requirement, corresponding with CIE 1931(2°) under CIE C light source.
Features
- 60° angle for semi-gloss
- Concise appearance, feel good
- Display 5 sets of measurement data
- Built-in lithium-ion rechargeable battery
- Basic model measurement can meet basic glossiness requirements
- Connect to PC, more extend functions
- One button for all angles measurement
Technical Specifications
| Measuring Angle | 60° Comply with standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457 |
| Measuring Area (mm) | 9×15 |
| Measuring Range | 0 to 300GU |
| Division Value | 0.1GU |
| Measurement Range Repeatability Reproducibility |
0-10GU 10-100GU 100-300GU ± 0.1GU ± 0.2GU ± 0.2%GU ± 0.2GU ± 0.5GU ± 0.5%GU |
| Measurement Standard | Conform with JJG696 first class glossmeter working requirement |
| Chromaticity Corresponding | Corresponding with CIE 1931(2°) under CIE C light source |
| Errors | ±1.5, ± 1.5% |
| Measuring Time | 0.5s |
| Dimension | 6.30 x 2.95 x 3.54 in (160.02mm × 74.93 mm × 89.92 mm) |
| Weight | 0.772 lb (350g) |
| Language | Chinese/English |
| Battery | 3.7V,3200mAh Li-ion Battery ，>10000 times (within 8 hours) |
| Display | TFT 3.5 inch |
| Interface | USB/RS-232 |
| Storage | Basic mode: 1000 |
| Software | GQC6 Quality Control Software with QC report printing functions and more extended functions. |
| Operation Temperature | 0 to 40℃（32 to104°F） |
| Storage Temperature | – 20 to 50℃（-4 to122°F） |
| Humidity | <85% relative humidity, no condensation |
| Standard Accessories | Power Adapter, USB cable, User Manual, GQC6 software CD (except HG60S), Calibration Plate |
| Optional Accessories | Miniature Printer |
