Features
- Motion sensor
- Support TCP (GPRS)
- 3D acceleration sensor
- GSM/GPS default built-in antenna
Technical Specifications
| SYSTEM | GPS+BEIDOU+GLONASS |
| Placement | Portable |
| Chipset | AT6558R |
| Receiver | 32 Channel |
| Cold start | ≤32 s |
| Hot start | ≤1 s |
| Cold start capture sensitivity | -148 dBm |
| Tracking sensitivity | -165 dBm |
| Resolution | 1920 x 1080 |
| Accuracy | <98.42 in (2500 mm) (CEP50） |
| Material | Engineering plastic |
| GPS Module | AT6558R |
| GSM module | Quectel M 25, EC 200 series or EC 25 series |
| Working temperature | -4 oF to 176 oF (-20 °C to 80 °C) |
| Store temperature | -40 oF to 176 oF (-40 °C to 80 °C) |
| Humidity | 5% RH to 99% RH |
| Built-in battery capacity | Rechargeable battery 10400 mAh |
| Average working current | <90 mA |
| Average current standby | <100 uA |
| Working hour | 2G device (10400 mAh) continuous full load operation for 100 hours3/4G device (10400 mAh) normal working mode: 70 hours |
| Waterproof | IP 67 |
| Transmission mode | Support TCP (GPRS) or SMS (short message) |
| Charging specification | DC 5 V, 2 A, 5521 interface |
| Motion sensor | 3D acceleration sensor |
| Memory | 2 MB |
| Antenna | GSM/GPS default built-in antenna |
| lock hook | Stainless steel, tensile resistance 440.92 lb (200 KG) |
| LED | 4 indicators (Communication, Location, Low power, Charge） |
| SIM | Double card single standby, Micro SIM card |
| Size | 7.67 in x 4.48 in x 1.45 in (195mm x 114mm x 37mm) |
| Weight | 1.83 lb (833 g) Include main unit and Hard lock hock soft rope |
