Technical Specifications
| Display Type | Digital Only |
| Measuring Range | ± (5% RDG + 2d) (2.00 to 199.9) Giga ohm ± (10% RDG + 2d) |
| Testing Voltage | 500 V, 1000 V; 2500 V; 5000 V |
| Working voltage | Rated voltage ± 10% load ≥ 20 Mili ohm |
| Output short circuit current | ≥2 mA |
| Insulation resistance | ≥50 Mega ohm (1000 V) |
| Withstand voltage | AC 3 kV 50 Hz 1 min |
| Humidity | <85% RH |
| Consume power | ≤150 mA; |
| Dimensions | 10.24 in x 7.09 in x 3.94 in (260 mm × 180 mm × 100 mm) |
