Technical Specifications
| Measure Range | 0 % to 53 % |
| Min Resolution Ratio | Brix: 0.1 % (Range for 15 % & 53 %) |
| Measurement Accuracy | Brix: ± 0.3 % (standard) |
| Operating Current | ≤ 200 mA |
| Display Menu | Refractive index (nD), Brix (%), Temperature (°C) |
| Output | 4 mA to 20 mA + RS485 optional |
| Power | 12 V DC to 24 V DC |
| Wetted Parts Material | Prism: sapphire, Prism stage: SS316L |
| Max Pressure | 1 MPa ( PSI) |
| Protection Grade | IP65 |
| Process Connection | 1/2NPT, other size supply free adaptor |
| Recorder Output Cable | 2.18 yd (2 m), 3.28 yd (3 m), 5.46 yd (5 m), 10.93 yd (10 m) |
| Temperature Sensor | Thin film platinum sensor |
| Measurement Temperature | 32 °F to 185 °F (0 °C to 85 °C) (Automatic Temperature Compensation) |
| Environment Temperature | 50 °F to 140 °F (10 °C to 60 °C) |
| Instrument Size | 9.05 in x 6.69 in x 2.55 in (230 mm x 170 mm x 65 mm) |
| Weight | 6.61 lb (3 kg) |
