Features
- Frame an entire scene in a single image
- Compare brake rotor temperatures for uniformity
- Quickly identify mechanical wear
- Troubleshoot mechanical issues
- Inspect tires and belts
- Reduce troubleshooting time
Technical Specifications
| Pixels | 100 x 100 |
| Spectral Response | 8 um to 14um |
| Frame Rate | 9 Hz |
| Field of View | 37°x 37° |
| Spatial Resolution | 6.5 mrad |
| Display Screen | 1.8″ TFT LCD, 128 x 160 |
| Humidity | ≤90% |
| Measurement Accuracy | ±2 °C or ±2% |
| Dist.to Spot Ratio (D.S) | 15:1 |
| Temperature Range | -4 °F to 302 °F (-20 °C to 150 °C) |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Storage Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Dimensions | 0.39 in x 0.11 in x 0.14 in (177 mm x 53 mm x 65 mm) |
| Weight | 6.88 lb (175 g) |
