Features
- Laser targeting for use from -22 °F to 662 °F (-30 °C to 350 °C)
- Small, rugged design easily fits your hand and your toolbox
- Easy-to-read, backlit LCD screen
Technical Specifications
| Response Time (95%) | 500 ms (95% of reading) |
| Spectral Response | 0.31 in to 0.55 in (8 mm to 14 mm) |
| Emissivity | 0.10 to 1.00 |
| Distance To Spot Ratio | 8:1 (calculated at 90% energy) |
| Display Resolution | 0.2 °F (0.1 °C) |
| Repeatability (% Of Reading) | ±1.0% of reading or ±1.0 |
| Power | 1 AA IEC LR06 Battery |
| Battery Life | 12 hours with laser and backlight on |
| Weight | 0.48 lbs. (0.22 kg) |
| Size | 6.14 in x 3.15 in x 2 in (156 mm x 80 mm x 50 mm) |
| Operating Temperature | 32 °F to 122 °F (0°C to 50°C) |
| Storage Temperature | -4 °F to 140 °F (-20 °C to +60 °C) (without battery) |
| Operating Humidity | 10% to 90% RH non-condensing @ 86 °F (30 °C) |
| Operating Altitude | 2000 meters above mean sea level |
| Storage Altitude | 12,000 meters above mean sea level |
| Drop Test | 1 m |
| Ingress Protection Rating | IP 40 per IEC 60529 |
| Vibration And Shock | IEC 68 to 2 to 6, 10 Hz to 200 Hz |
| Compliance | EN to IEC 61010 1 |
| Laser Safety | FDA and EN 60825 to 1 Class II |
| Temperature Range | -22 °F to 662 °F (-30 °C to 350 °C) |
| Electromagnetic Compatibility | 61326 to 1 EN |
