Features
- Thermal imager
- Infrared camera
- High resolution
- Non-contact measurement
- Wide temperature range
- Fast response time
- Rugged design
Technical Specifications
| Detector type | Uncooled vanadium oxide micro radiation calorimeter |
| Detector resolution | 160 px × 120 px |
| The response wave band | 8 μm to 14 μm |
| Pixel Size | 17 um |
| accessories | 5V power adapter, USB cable, wrist strap lanyard, 8GB microSD card, documentation |
| NETD | < 50 mk |
| Focal length of thermal imaging lens | f3.1 There is no heating in the fixed focus. |
| Minimum measuring distance | 5.90 in (150 mm) |
| field angle | 38.3° × 50° |
| accuracy | ± 2% (maximum) |
| Temperature measurement range | -4 °F to 1022 °F (-20 ℃ to 550 ℃) |
| Operation Temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
| Storage Temperature | -40 °F to 158 °F (-40℃ to 70℃) |
| Size | 7.71 in x 3.07 in x 2.32 in (196 mm x 78 mm x 59 mm) |
| Weight | < 0.77 lb (350 g) (including battery) |
