Features
- Suitable for low target emissivity
- OK for partially blocked or obscured field of view to the
- Applicable to smaller target than the sensor’s field of
- Results are closer to the summit temperature of the target instead of average
- Good at to obtain accurate measurement results when target vibrated
- Appropriate to the environment with dust, smoke, water vapour
- Even a small amount of steel slag
Technical Specifications
| Measurement Range | 1472 °F to 3272 °F (800 ºC to 1800 ºC) |
| Spectral Range | 0.8 µm to 1.1 µm or 0.4 µm to 1.1 µm |
| Distance-To-Spot Ratio (D:S) | 280:1 |
| Accuracy | ±0.75% (FS) |
| Repeatability | 0.2% |
| Response Time (95%) | ≤5 ms |
| Temperature Resolution(Analog) | 32.9 °F (0.5 ºC) |
| Temperature Resolution(Digital) | 32.18 °F (0.1 ºC) |
| Output | 0 mA to 20 mA or 4 mA to 20 mA or 0 V to 5V |
| Power | 24 V DC, 100 mA |
| Ambient Temperature Range | 32 °F to 158 °F (0 ºC to 70 ºC) |
| With Air Cooling | 248 °F (120 ºC) |
| With Water Cooling | 587 °F (175 ºC) |
| Storage Temperature Range | -4 °F to 158 °F (-20 °C to 70 °C) |
| Dimensions | 7.28 in x 2.28 in (185 mm x 58 mm) |
