Technical specification
| Pressure range | 0 Mpa to 1 Mpa |
| Sampling flow | 0.6 L/min ±20% |
| Humidity | 0% RH to 100% RH |
| Resolution of the dew point value | 32.18 °F (0.1 ℃) |
| Resolution of the moisture content | 1 uL/L |
| Charging time | 4 hours |
| Accuracy of measurement | 31.1 °F to 32.9 °F (±0.5 ℃) -76 °F to 68 °F (-60 ℃ to 20 ℃) |
| Response time (+20℃, 0.1mpa) | 63% need 5 s,90 % need 45 s 112 °F to 68 °F (-80 ℃ to 20 ℃) 63% need 10 s,90 % need 240 s 68 °F to 112 °F (20 ℃ to -80 ℃) |
| Measuring range dew point value | 112 °F to 68 °F (-80 ℃ to 20 ℃) |
| Measuring range moisture content | 0 uL/L to 19999 uL/L |
| Temperature | -4 °F to 140 °F (-20 ℃ to 60 ℃) |
| The whole machine size | 17.71 in × 5.90 in × 11.81 in (250 mm × 150 mm × 300 mm) |
| Machine weight | 9.7 lb (4.4 kg) |
