Overview
This industrial crack detector has high-brightness color 5.7 in display, data storage, lithium Battery 5000mAh and 0 in to 393.70 in testing range.
Technical Specifications
| Testing Range | 0 in to 393.701 in (0 mm to 10000 mm) |
| Velocity Range | 1000 to 15000 m/s |
| Pulse Shift | -7 to + 9984 us |
| Frequency Range | 0.5 to 20 Mhz |
| Gain | 0 to 120 dB |
| Dynamic Range | ≥ 32 dB |
| Display Screen | High-brightness color 5.7 in display |
| Flaw Detection Channel | 300 |
| Data Storage | 500 A-Scan graphics |
| PC Communication Interface | USB |
| Power Adapter | 100 V to 240 V / 50 Hz to 60 Hz Output 9V/1.5A |
| Battery | Lithium (Li) Battery 5000 mAh |
| Interface Type | BNC |
| Dimensions | 8.66 in x 5.52 in x 1.97 in (220 mm x 140 mm x 50 mm) |
| Weight | 2.20 lbs. (1.0 kg) |
