Overview
This industrial crack detector has a measuring range of width from 0 in to 0.32, accuracy of 0.01, working temperature of 50° F to 122° F.
Features
- Large color LCD screen 5 in, Resolution: 640 * 480
- Automatic interpretation
- Variety of interpretation methods
- Max detects depth: 25.59 in (650 mm).
- Special scale, Portable and practical, improve the test efficiency.
- Convenient data transmission, connect with computer, transmit pictures and data.
- Analyze test data of the software.
Technical Specifications
| Measuring Range Of Width | 0 in to 0.32 in (0 mm to 8 mm) |
| Accuracy | 0.01 |
| Large Capacity Of Storage | 100,000 group detect picture or data |
| Measuring Range Of Depth | ≤ 25.59 in (≤ 650 mm) |
| Tolerance Of Detecting Depth | ≤ 10 % |
| Tolerance Of Detecting Width | 0.0003937 in (0.01 mm) |
| Test Data Storage | 6000 group testing data |
| Work Temperature | 50° F to 122° F (10° C to + 50° C) |
| Weight | 2.116 lbs. (960 g) |
