Technical Specifications
| Resolution | 256 pixel x 192 pixel |
| Spectral band | 8 μm to 14 μm |
| Pixel pitch | 12 μm |
| NETD | <50 mk |
| Frame rate | 25 Hz |
| FOV | 56° x 42.2° |
| IFOV | 3.8 mrad |
| Accuracy | ±2 °F or ±2% reading |
| Resolution | 0.1 °F |
| Display size | 2.8 in |
| Drop protection | 2 m |
| Working environment | 14 °F to 122 °F (-10 °C to 50 °C) |
| Storage environment | -4 °F to 140 °F (-20 °C to 60 °C) |
| Dimension | 9.33 in x 2.95 in x 3.62 in (237 mm x 75 mm x 92 mm) |
| Weight | 1.14 lb (520 g) |
