Technical Specifications
| Measure Range | 0 % to 53% |
| Min Resolution Ratio | Brix 0.1 % ( Range for 15 % & 53 % ) |
| Measurement Accuracy | Brix ±0.3% (standard) |
| Measurement Temperature | 32 ℉ to 185 ℉ (0 ℃ to 85 ℃) (Automatic Temperature Compensation) |
| Operating Current | ≤200 mA |
| Display Menu | Refractive index(nD), Brix (%), Temperature (° C) |
| Output | 4 mA to 20 mA, 4 mA to 20 mA+ RS 485 optional |
| Power | 12 V to 24 V DC |
| Wetted Parts Material | Prism sapphire, Prism stage SS 316 L (can be customized) |
| Max Pressure | 1 MPa |
| Environment Temperature | 50 ℉ to 140 ℉ (10 ℃ to 60 ℃) |
| Protection Grade | IP 65 |
| Instrument Size | 9.055 in × 6.692 in × 2.559 in (230 mm x 170 mm x 65 mm) |
| Process Connection | 1/2 NPT, other size supply free adaptor |
| Recorder Output Cable | 2 M ,3 M ,5 M,10 M optional |
| Temperature Sensor | Thin film platinum sens |
