Technical Specifications
| Measurement range | -40 °F to 248 °F (-40 °C to 120 °C) |
| Accuracy (at +25 °C) | 32.54 °F to 31.46 °F (± 0.3 °C) |
| Working temperature | -40 °F to 176 °F (-40 °C to 80 °C) |
| Storage temperature | -40 °F to 176 °F (-40 °C to 80 °C) |
| Oil temperature permitted | -40 °F to 248 °F (-40 °C to 120 °C) |
| Pressure range | Max 100 bar |
| Resistance load | 250 Ω to 500 Ω |
| Supply voltage | DC 9 V to 36 V, >DC 15 V (use 4 mA to 20mA) |
| Cable specification | M8 6 pin |
| Cable length | 2 m |
| Dimensions | 6.7 in x4.6 in x 2.0 in (172 mm × 117 mm×53 mm) |
| Weight | 7.76 oz (220 g) |
