Features
- On grid pure sine wave
- Maximum power point tracking
- App monitoring system
- Output over and under voltage protection
- Adaptive voltage and frequency
- Over temperature protection
- Anti-islanding protection
- No installation and no maintenance
- Multiple parallel stacks
Technical Specifications
| Inverter Efficiency | 91 % |
| Input Voltage | 20 to 50 V |
| Output Voltage | 90 to 160 V or 190 to 270 V |
| Output Frequency | 50 to 60 Hz |
| Controller Type | MPPT solar controller |
| Communication Way | WIFI 2.4 G and Bluetooth |
| Waterproof Grade | IP 65 |
| Input Interface (Set) | 2 |
| Recommended Solar Panel Input Power (W) | 275 to 400 W |
| DC Input Connections | 2 MC 4 |
| Operating Voltage Range | 52 V |
| Start Up Voltage | 18 V |
| MPPT Tracking Range | 22 to 48 V |
| MPPT Tracking Accuracy | Over 99.5 % |
| Maximum DC Input Current | 2 12 A |
| Rated Power | 750 W |
| Max Rated Power | 800 W |
| Rated Output Voltage | 230 V |
| Rated AC Current | 120 V 6.6 A and 230 V 3.47 A |
| Output Frequency Range | 58.9 to 61.9 Hz |
| THD | Less than 5 % |
| Power Factor | Over 0.99 % |
| Max Number Of Branch Circuit Connections | 5 sets of 120 VAC and 10 sets of 230 VAC |
| Maximum Conversion Efficiency | 94 % |
| CEC Efficiency | 92 % |
| Night Losses | Less than 80 mW |
| Indicator Lights Quantity | Working status and 1 LED light and 1 signal WIFI LED light |
| Cooling Method | Natural cooling (no fan) |
| Working Environment | Indoor and outdoor |
| Ambient Temperature Range | – 40 °F to 140 °F (- 40 °C to 60 °C) |
| Size | 7.87 in x 12.2 in x 1.5 in (20 cm x 31 cm x 3.8 cm) |
| Weight | 5.51 lb (2.5 kg) |
