Features
- Temperature range: 32 °F to 2192 °F (0° C to 1200 ℃)
- Housing material: Stainless steel
- Spectral response: 8 um to 14 um
- Accuracy and repeatability: High
- Response time: ≤ 200 ms
- Internal power protection for serious situations
- Coaxial laser aiming
- Adjustable emissivity: 0.10 to 1.00
- Output options: 4 mA to 20 mA, RS485
- Installation and maintenance: Easy
Technical Specifications
| Accuracy | 0.5 % FS |
| Application | Industrial Temperatures Monitoring |
| Output | 4 mA to 20 mA |
| Color | Silver |
| Emissivity | 0.10 to 1.00 Adjustable |
| Material | Stainless Steel |
| Spectral response | 8 um to 14 um |
| Response time | ≤ 200 ms |
| Adjustable emissivity | 0.10 to 1.00 |
| Resolution | 33.8 °F (1 ℃) |
| Temperature range | 32 °F to 2192 °F (0 ℃ to 1200 ℃) |
