Features
- High accuracy positioning
- Spiral antenna design
- Multi constellation support
- Rugged and durable
- Wide bandwidth
- Compact and lightweight
Technical Specifications
| Frequency range | GPS L1 / L2, BDS B1 / B2, GLONASS L1 / L2 |
| Impedance | 50 Ω |
| Polarization | RHCP |
| Horizontal plane coverage angle | 360° |
| Working voltage | 3.3 V DC to 12 V DC |
| Working Current | ≤55 mA |
| Connector | SMA male |
| Working temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Storage temperature | -67 °F to 158 °F (-55 °C to 70 °C) |
| Humidity | 95% (non-condensation) |
| Color | Black |
| Gain | 33±2 dB |
| Noise factor | ≤2 dB |
| Antenna size | 1.12 in x 2.32 in (27.5 mm x 59 mm) |
| Weight | ≤0.1 lb (≤25 g) |
