Overview
Hospitality Enviro Tech High Accuracy Concrete Crack Detector is mainly used for crack width and crack depth measurement of bridges, tunnels, buildings, roads and so on.
Features
- Standard probe and high-grade probe
- Two detection methods: standard and simple depth measurement
- Standard ultrasonic transducer bracket, precise and adjustable; free from scene marking out, which can greatly improve the detection efficiency
- Image automatic recognition and width intelligent computing technology; crack position without adjustment
- Crack automatic identification and calculation; real-time display
- Friendly human-computer interactive interface
- Various built-in various helpful files and demo videos facilitate the users to conduct skilled instrument operation
- 4GB large-capacity SD card can store more than 100,000 data
Technical Specifications
| Hardware Platform | Embedded ARM9 Hardware Platform, WinCe5.0 Operating System, True Color TFT Touch Screen |
| Crack Width Test Range | Standard Probe: 0.01 mm to 6.5 mm; |
| Crack Width Test Accuracy | Standard Probe: ≤±0.02 mm |
| Crack Depth Test Range | 0.39 in to 19.69 in (10 mm to 500 mm) |
| Crack Depth Accuracy | ≤±5% |
| Image Storage Format | BMP or JPEG |
| Power Supply | Rechargeable Lithium Battery |
| Working Time | ≥28 Hours |
| Working Temperature | -50 °F to 122 °F (-10℃ to +50℃) |
| Working Humidity | ≤90%RH |
