Features
- Route measurements downloaded from PC software
- Time waveform/spectrum analysis
- Manual input function
- Integrated 30:1 infrared temperature measurement
- Optional one plane balancing function
- 1GB memory capacity
- i-Button Electronic navigation
- Output to computer Set equipment status Anti-explosion version is available and optional
- CE marking available RFID card compatible
- USB & Wi-Fi communication
- Rechargeable lithium battery Small size and light weight
- The thickness gauge uses a high-resolution true-color LCD
Technical Specifications
| Parameter | Index |
| Input | CH1: Vibration (ICP accelerometer), Voltage (±5V AC) |
| Frequency Range | 2 to 10000Hz |
| Precision | ±2% |
| Sampling Frequency | Maximal 25.6 kHz |
| Hardware Integral | Integration, double integration |
| A/D Conversion | 16 bits |
| Harmonic Distortion | <-70 dB |
| Sampling Number | 1,024,204,840,968,190 |
| Lines | 400, 800, 1600, 3200 |
| Averaging | Linearity, Peak hold |
| Window Type | Rectangle, Hanning |
| Temperature Range | 32 °F to 572 °F (0 ℃ to 300 ℃) |
| Precision | ±2%, ±34 °F (2 ℃) Maximal |
| Emission Rate | 0 to 1 adjustable |
| Distance Coefficient | 30:01:00 |
| Balancing Method | Influence coefficient |
| Pase | Use external tachometer |
| Dimension | Height × width × depth: 2.2047 in × 3.1496 in × 1.8110 in. (56 mm × 80 mm × 46 mm) Grip size (width × depth): 2.0472 in × 1.1024 in. (52 mm × 28 mm) |
| LCD | 3.5 in, 320×240 pixels, 260K true color |
| Weight | 0.606 lbs. (275 g) |
| Keyboard | 21 keys 1 million times lifespan |
| RPM Measurement Range | 10-10000 RPM |
| Working Environment | Temperature: 14°F to 122°F (-10 ℃ to 50 ℃), humidity:< 95% (without condensate) |
| IP Grade | IP54, dustproof, waterproof |
| Charging Time | About 4 hours |
| Working Time | >10 Hours |
| Communication | USB 2.0 |
| Storage Capacity | 1 GB |
| I-button | I-button 1990 A |
| Radio Frequency Identification | RFID Frequency:13.56 MHz, Detection distance: within 3 cm (not standard configuration, optional) |
| Anti-Explosion | ExibIIBT3 |
