Technical Specifications
| Millivolt Range and Accuracy | -10 mV to 75 mV ± (0.005% 5 uV) |
| Resistance Range and Accuracy | 0 Ω to 400 Ω ± (0.004% 0.002 Ω), 200 Ω to 50 KΩ ± (0.01 or 0.5Ω) ,50 KΩ to 300 KΩ ± (0.03%) |
| RTD Equivalent Temperature Accuracy 4 wire probe | ±0.02 ℉ (±0.011 ℃) at -148 ℉ (-100 ℃), ±0.03 ℉ (±0.015 ℃) at -32 ℉ (-0 ℃), ±0.03 ℉ (±0.019 ℃) at 212 ℉ (100 ℃) ,±0.04 ℉ (±0.023 ℃) at 392 ℉ (200 ℃), ±0.06 ℉ (±0.031 ℃) at 752 ℉ (400 ℃), ±0.07 ℉ (±0.039 ℃) at 1112 ℉ (600 ℃) |
| Thermistor Equivalent Temperature Accuracy | ±0.004℉ (±0.002 ℃) at 32 ℉ (0 ℃), ±0.01 ℉ (±0.003 ℃) at 77 ℉ (25 ℃), ±0.01 ℉ (±0.01 ℃) at 122 ℉ (50 ℃), ±0.03 ℉ (±0.014 ℃) at 167 ℉ (75 ℃), ±0.05 ℉ (±0.03 ℃) at 212 ℉ (100 ℃) |
| Type K Range and Measurement Accuracy | -328 ℉ to 32 ℉ (-200 ℃ to 0 ℃) at ±1.098 ℉ (±0.61 ℃) 32 ℉ to 2498 ℉ (0 ℃ to 1370 ℃) at ±0.432 ℉ (±0.24 ℃) |
| Type T Range and Measurement Accuracy | -328 ℉ to 32 ℉ (-200 ℃ to 0 ℃) at ±1.08 ℉ (±0.60 ℃) 32 ℉ to 752 ℉ (0 ℃ to 400 ℃) at ±0.45 ℉ (±0.25 ℃) |
| Type S Range and Measurement Accuracy | -328 ℉ to 32 ℉ (-200 ℃ to 0 ℃) at ±1.89 ℉ (±1.05 ℃) 32 ℉ to 932 ℉ (0 ℃ to 500 ℃) at ±1.71 ℉ (±0.95 ℃) 932 ℉ to 3182 ℉ (500 ℃ to 1750 ℃) at ±1.01 ℉ (±0.56 ℃) |
