| Detector type |
Uncooled vanadium oxide micro radiation calorimeter |
| Detector resolution |
160 × 120 |
| The response wave band |
8 µm to 14 µm |
| Pixel Size |
17 um |
| NETD (Noise equivalent temperature difference)
|
< 50 mk (@25°C.F#=1.0) |
| Focal length of thermal imaging lens |
f3.1 There is no heating in the fixed focus |
| Field angle |
38.3 degrees × 50 degrees |
| Aperture |
F1.1 |
| Accuracy |
± 0.5 % (maximum) |
| Temperature measurement range |
86 ℉ to 113 ℉ (30 ℃ to 45 ℃) |
| Temperature measurement unit |
Degrees Celsius, Fahrenheit, Kelvin |
| Maximum image size |
160 × 120 |
| frame rate |
25 Hz |
| Display |
2.4 in LCD screen (320 x 240) |
| Picture mode |
White Heat, Black Heat, Iron Red, Rainbow |
| Laser pointer |
The laser indicates the temperature measurement area and is activate button |
| Memory |
8 GB Micro SD card |
| Storage extension |
Maximum support 128 GB |
| Power Interface |
Micro USB, Fill continuously |
| Type of battery |
Rechargeable lithium-ion batteries |
| Recharged time |
< 3H @25 C |
| Battery life |
> 8H @25 C |
| Power Management |
The adjustable: Off, 5 minutes, 10 minutes, 20 minutes |
| Working Humidity |
≤ 95 % |
| Protection grade |
IP54 |
| accessories |
5 V power adapter, USB cable, wrist strap lanyard, 8 GB microSD card |
| Storage Temperature |
– 40 °F to 158 °F (- 40 ℃ to 70 ℃) |
| DROP TEST |
6.56 feet (2 m) |
| Minimum measuring distance |
5.90 in (15 cm) |
| Operation Temperature |
5 °F to 95 °F (- 15 ℃ to 35 ℃) |
| Weight |
12.34 oz (350 g) (including battery) |
