Overview
Hospitality Enviro Tech handheld gas detector uses international advanced tunable diode laser absorption spectroscopy technology (TDLAS), which can detect methane gas within a certain distance. At the same time, through optimization design and independent research and development, the detection distance and accuracy of the detector are greatly improved, which is the most powerful safety guarantee for gas inspection and leak detection.
Technical Specifications
| Detection Method | Handheld Laser Portable Gas Detectors |
| Detection Gas | Methane |
| Measurement Method | Laser Reflection |
| Measurement Range | 0 ppm to 99,999 ppm |
| Detection Distance | 196.85 feet (60 m) nominal. Actual distance may vary due to background type and conditions |
| Sensitivity | 5 ppm at distances from 49.21 feet (0 m to 15m) 10 ppm or better from 49.21 feet to 328.08 feet (15 m to 100 m) |
| Measurement Accuracy | ±10% |
| Response Time | 0.1 S |
| Detection Alarms Modes | Buzz with LCD turning red |
| Laser Eye Safety | IR Detector Laser: Class I Green Spotter Laser: Class IIIa; Do not stare into beam or view directly with optical instruments. |
| Display | Large easy to read backlit LCD |
| Compliance | EMC (EN61000 6 2, EN6100 6 4) Pending |
| Self Test & Calibration | Built-in Self-Test and Calibration function verifies operation and adjusts laser wavelength for maximum sensitivity. Test gas cell integrated with carrying case. |
| Battery | Rechargeable Lithium battery |
| Battery Operating Life | 8 hours (Internal battery) |
| Battery Charger | External, in-line, 220 V AC, 50 per 60 hertz universal type with charge indicator |
| Enclosure | IP54 (Water splash and Dust resistant) |
| Size | 8.11 in × 7.87 in × 2.99 in (206 mm × 200 mm × 76 mm) |
