| System kernel |
Using a multi-star system core |
| Number of channels |
800 |
| BDS |
B1, B2, B3 |
| GPS |
L1, L2,L5 |
| GALILEO |
E1,E5a,E5b |
| SBAS |
Yes |
| Output format |
ASCII: NMEA-0183, binary code |
| Positioning output frequency |
1Hz to 20 Hz |
| Differential support |
CMR, RTCM2.X, RTCM3.0, RTCM3.2 |
| Static format support |
GNS, Rinex dual format static data |
| DGPS positioning accuracy |
Plane accuracy: ±0.25m+1ppm; Elevation accuracy: ±0.50m+1ppm |
| SBAS positioning accuracy |
1.64 ft (0.5 m) |
| Initialization time |
<10 sec |
| Initialization reliability |
＞99.99% |
| network |
Built-in 4G full Netcom network communication |
| WiFi |
802.11b/g access point and client mode can provide WiFi hotspot service |
| Bluetooth |
Built-in Bluetooth |
| Power |
1W/2W/5W adjustable |
| frequency band |
403 MHz to 473 MHz |
| Transmission rate |
19.2 kbps/9.6 kbps adjustable Number of channels: 116 frequency bands adjustable |
| panel |
Single button |
| Indicator light |
Satellite lights, signal lights, power lights |
| Display screen |
Industrial-grade OLED HD color display, capacitive touchscreen |
| Smart service |
Voice broadcast, voice guidance, function self-check, DIY voice |
| Remote Service |
Remote upgrade, remote registration, remote data download |
| battery |
High-capacity lithium battery 6800 mAh |
| Input voltage |
DC 6 V to 28 V DC, with over-discharge protection |
| Power consumption |
4.2 W |
| material |
Shell is made of magnesium alloy material |
| Dust and water release |
IP 67 |
| Anti-fall |
Resistance to natural drop of 3 meters |
| operating system |
Android 10 |
| processor |
CPU: 8 core; 2.0 GHZ |
| storage |
2 GB RAM+16 GB ROM; T-Flash memory card, up to 128 GB |
| display |
5.5 in (139.7 mm), bright Outdoor Color touch screen (with touch pen, can be operated with gloves) |
| enter |
Physical full keyboard |
| Cellular mobile |
Built-in 4G full Netcom, dual card dual standby |
| WiFi |
802.11 b/g access point and client mode, can provide WiFi hotspot service |
| Bluetooth |
Built-in Bluetooth |
| NFC |
Support NFC IGRS |
| USB |
USB, TypeC interface, OTG |
| Built-in battery |
7500 mAh internal |
| Working time |
14 h |
| Operating temperature |
-4 °F to 140 °F (-20 ℃ to +60 ℃) |
| size |
9.29 in x 3.35 in x 0.98 in (236 mm x 85 mm x 25 mm) |
| Weight |
1.06 lb (480 g) |
