Technical Specifications
| Frequency | 865 MHz to 868 MHz (EU) or 902 MHz to 928 MHz (US) |
| Protocol | ISO18000-6C (EPC GEN2) |
| Application | Warehouse Management |
| Type | Waterproof RFID Reader |
| Read Range | 1.9 in to 3.9 in (5 cm to 10 cm) |
| Communication Interface | RS232 (WiFi or 4G Optional) |
| Function | RFID Reader Component |
| Support | Android Ect |
| Processor | Quad Core Cortex-A55 (2.0 GHz) |
| Memory | 2 GB + 16 GB |
| Operating System | Android 12 |
| Firmware upgrade | Local USB upgrade |
| WIFI | 2.4 G or 5 G dual mode 802.11 a/b/g/n/ac/d/e/h/i/k/r/v, IPV4, IPV6 |
| SDK | Host applications – Net, C and Java EMDK Embedded applications – C and java SDK |
| Power Output | 0 dBm to 33 dBm |
| Receiver Sensitivity | – 88 dBm |
| Max query speed | 900 tags per s |
| Reading Distance | 0 ft to 82.0 ft (0 m to 25 m) |
| Power Supply | Default DC 24 V input Support DC 9 V to 30 V input |
| Antenna Port | 8 X SMA female |
| Communicate | USB (3.0 Type A or OTG) RS232. RS485. TCP or IP |
| GPIO | 2 inputs, 2 outputs optocoupler isolation(terminals) |
| Management protocol | HDMI type A, 1080p high-definition video output |
| Housing Material | Die-casting aluminum |
| Visual Status Indicator | Multicolor LEDs: Power, Running, Status |
| Operation Temperature | -4 °F to 149 °F (-20 °C to +65 °C) |
| Storage Temperature | -40 °F to 176 °F (-40 °C to +80 °C) |
| Dimension | 7.0 in X 1.0 in X 5.0 in (180 mm x 129 mm X 27 mm) |
| Weight | 21.1 oz (600 g) |
