Features
- Wide Test Range (Up to 10000)
- Fast Test Speed (Single-phase in 5 seconds)
- 240 x 128 Color LCD for Intuitive Interface
- Z-Connection Transformer Testing
- Transformation Ratio, Group Test, Tap Position Functions
- Clock, Date Display, Data Storage (850 sets)
- High or Low Voltage Reverse Connection Protection
- Short Circuit and Inter Turn Protection
- Lithium Battery Pack for Smart, Lightweight Power
- Compact, Lightweight, Portable Size
Technical Specification
| Power | Electronic |
| Range | 0.9 to 10000 |
| Accuracy 1 | 0.1% ±2 numeric (0.9 to 500) |
| Accuracy 2 | 0.2% ±2 numeric (500 to 2000) |
| Accuracy 3 | 0.3% ±2 numeric (2000 to 4000) |
| Accuracy 4 | 0.5% ±2 numeric (4000 above) |
| Resolving Power | minimum 0.0001 |
| Output Voltage | 160 V or 10 V (Auto shift) |
| Service Temperature | 14° F to 104° F (-10° C to 40° C) |
| Relative Humidity | ≤80%, No condensation |
| Working Power Supply | the instrument is equipped with lithium battery |
