Features
- High Output Power
- Durable Construction
- Equipotential Protection
- Active Low-Pass Filter
- Quick Voltage Rise
- Proportional Design
- Battery-Powered
- Automatic Range Switching
- User-Friendly Interface
- Direct Short-Circuit Current Measurement
Technical Specification
| Measuring Range | 0 G ohms to 200 G ohms |
| Testing Voltage | 500 V, 1000 V, 2500 V, 5000 V |
| Accuracy Class | 10% RDG to 1 d |
| Color | As Picture Shows |
| Size | Standard Size |
| Accuracy | High Accuracy |
| Environmental Temperature | 32° F to 113° F (0° C to +45° C)
Relative humidity ≤85% RH |
| Output Voltage Level | 1000 V, 2500 V, 5000 V, 10000 V |
| Measurement Range | 0 to 500 G Ω |
| Resolution | 0.01 MΩ, 0.1 MΩ, 1.0 MΩ, 10.0 MΩ, 1 GΩ |
| Relative Error | ≤± 4% ±1 d |
| Working Voltage (V) | Rated voltage ± 10% Load ≥20 MΩ |
| Measurement Range and Error | (1 to 1999) M Ω ± (5% RDG+2d), (2.00 to 199.9) G Ω ± (10% RDG+2d) |
| Output Short-circuits Current | ≥1 mA |
| Insulation Resistance | ≥50 M (1000 V) |
| Withstand Voltage | AC 3 kV 50 Hz for 1 min |
| Working Temperature and Humidity | 14° F to 122° F (-10° C to +50° C) <85% RH |
| Operating Temperature | 32° F to 104° F (0° C to 40° C) |
| Power Supply | DC 12 V lithium battery |
| Power Consumption | ≤150 mA |
| External Dimensions | 10.2 in × 7 in × 3.9 in (260 mm × 180 mm × 100 mm) |
| Display Type | Digital Only |
| Dimensions | 12.5 in × 9.8 in × 4.7 in (320 mm × 250 mm × 120 mm) |
| Weight | 2.2 Ib (1 kg) |
