Overview
Hospitality Enviro Tech dust particle air quality tester is a test instrument applied to cleanliness monitoring and micro-particle counting detection in clean environment. The counter is theoretically based on the light scattering principle and achieves the detection of dust particle size and particle count through photoelectric sensing technology. It has the features of visualization for easy calibration, good stability, high measurement accuracy, small size, light weight, easy installation, etc. It is widely used in clean scenes of pharmaceutical, electronics, semiconductor, hospital operating room, aerospace, precision processing, environmental protection, microbiology, food industry, etc.
Features
- High precision sensor, accurate counting, excellent performance
- Compact size and easy installation
- 3 in (10.9 cm) intelligent touch screen
- Internal vacuum source, life > 10000 hours, stable performance
- More professional industrial design
- Can be started and stopped individually and locally
- Can set its own instrument address directly on the screen
- Calibration expiration prompt
- Screen data alarm, with flow sensor real-time monitoring
- Long life Japanese imported semiconductor laser source
- Intelligent IOT, remote start
- Expandable, with analog access hardware interface
- With U disk data export function
- Real-time monitoring of the number of particles
- The counter comes with an audible and visual alarm light, >85 dB
- The counter can be upgraded to wireless transmission mode
Technical Specifications
| Particle size range | 0.3 µm to 10.0 µm |
| Particle size channel | 0.5 µm, 5.0 µm |
| Particle size distribution error | ≤± 30 % |
| Concentration error | 0.5 μm ≤± 30 % FS |
| Maximum sampling concentration | 35000 pieces per liter, concentration over limit protection, and prompt instrument self-cleaning |
| Repetition error | ±10 % F.S |
| Self-cleaning time | ≤10 min |
| Sampling flow rate | 2.83 L ± 5 % |
| Sampling period | 1 second to 9999 seconds can be set |
| Continuous work | Support 24 hours uninterrupted and stable work |
| Laser light source | Long life Japanese imported semiconductor laser diode |
| Vacuum | Internal vacuum source, lifetime > 10000 hours |
| Show | 4.3 in (10.9 cm) touch screen |
| Power supply | DC 24 V or 1 A |
| Housing | 304 stainless steels |
| Working temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Working humidity | 10 % to 90 % non-condensation |
| Storage temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
| Storage humidity | 0 % to 90 % non-condensation |
| Size | 3.7 in x 7.0 in x 3.1 in (9.4 cm x 17.8 cm x 8.0 cm) |
