Overview
Hospitality Enviro Tech dry film coating thickness gauge meter is using the magnetism and back set measuring thickness method. It can measure the thickness of the magnetism metal substrate, non-magnetism cover layer and non-magnetism metal substrate and non-transmitting electricity cover layer. This instrument has small error of measure, excellent performance and good stability, easy operation and other characteristics, is a necessary measure instrument to control and guarantee the product quality, can be widely applied to manufacturing, metal processing industry, chemical industry, merchandise test fields.
Features
- Precise measurements (2% +1)/(1% +1)
- Quick measuring response and rapid measuring speed
- Design of two independent parts
- Better applicability
- Stable measurement results
- Strong data processing and analysis
- 5 types of Statistic value and histogram
- 7 types of probes are available
- Suitable to requirements of different customers
- CTG Insight data processing platform
- Enable analysis and management of data
Technical Specifications
| Measuring range | 0 μm to 400μm |
| Measuring accuracy | 1 point calibration:±(2% +0.7) 2 point calibration:±(1%+7) |
| Calibration | 1 point calibration /2 point calibration /basic calibration |
| Display resolution | 0.1 um (0 um to 99.9 um) / 1 um (Over 100 um) |
| Operation mode | Direct testing mode and block statistics mode |
| Measuring mode | continuous/single |
| Operation alarm | Ring music to alarm mistake |
| Battery | 9 V Nickel-hydride/alkaline batteries |
| Communication | RS 232/USB |
| Shutdown mode | manual/automatic |
| Weight | 0.55 lb (250 g) including battery package |
| Operation environment | Temperature: 32 °F to 122 °F (0 °C to 50 °C), humidity: 20% RH to 90% RH |
