Features
- Pure sine wave solar inverter (on or off Grid)
- Output power factor 1.0
- WIFI and GPRS available for lOS and Android
- Inverter can run without battery
- One-key restoration to factory Settings
- Built-in Lithium battery automatic activation
- Built-in 120 A (for 3.6 KW or 5 KW)
- MPPT: Max 4200 w (for 3.6 KW) and max 6000 w (for 5 KW) solar charge
- High PV input voltage range (90 to 450 VDC) Built-in anti-dust kit for harsh environment
- Smart battery charge design to optimize battery life
- Dual output
Technical Specifications
| Full Load | 3600 W or 6200 W |
| Phase | 1 phase |
| Voltage | 220 or 230 or 240 VAC |
| Frequency Range | 50 Hz or 60 Hz (Auto sensing) |
| AC Voltage Regulation | 230 VAC plus or minus 5 % |
| Maximum Conversion Efficiency (Solar To Ac) | 98 % |
| Battery Voltage | 24 VDC or 48 VDC |
| Output Power | 3 KW |
| Nominal Output Current | 157 A or 270 A |
| Nominal DC Voltage | 360 VDC or 500 VDC |
| MPPT Range At Operating Voltage | 90 to 450 VDC |
