Features
- Handheld can be paired with up to 20 dogs
- Touch screen handheld with Android system
- You can choose any languages
- Handheld IP67, Collar IP68 waterproof
Technical Specifications
| LTE Module | Qualcomm SM8909 |
| Frequency | LTE-FDD / TDD, WCDMA, GPRS, GSM,EDGE, (B1 / B2 / B3 / B5 / B7 / B8 / B38 / B40 / B41)
Optional: B4/ B12 / B13 / B17 / B25 / B26 / B34) |
| LTE/GPS Antenna | Built-in (VHF antenna externally connected) |
| GPS Cold Boot Positioning Time | 36 s |
| Standby Current | <10 mAH |
| Battery | 7000 mAh |
| Storage Temperature | -31 oF to 158 oF (-35 oC to 70 oC) |
| Battery Working Time | 32 hours in integrated mode, 24 hours in continuous-use mode, and 120 hours in standby mode |
| GPS data storage | Local |
| Built-in Memory | 8GB (optional 32GB to 128GB) |
| Battery Type | 18650 |
| Charge Type | 1A current fast charging type |
| GPS Module | UBLOX |
| WIFI | 802.11 a / b / g / n |
| Working Current/Voltage | GPRS<90 mA/5 VVHF<1500 mAH |
| Data Transmission | VHF/WCDMA/GPRS wireless transmission module |
| GPS Warm Boot | 1 s |
| GPS Sensitivity Tracking | -162 dBm capture- 160 dBm |
| Working Temperature | -4 oF to 140 oF (-20 oC to 60 oC) |
| IP Rate | IP 67 |
| SIM Card | Micro SIM Card |
| Sensor Type | Geomagnetic sensor, three-axis gravity sensor, gradient |
| Positioning Accuracy | 39.37 in to 196.85 in (1000 mm to 5000 mm) |
| Interface | Type-C |
| Working Charging Voltage | 5V DC |
| Screen Resolution | 480 x 800 |
| Size | 5.70 in x 2.55 in x 1.29 in (145 mm x 65 mm x 33 mm) |
