Overview
Hospitality Enviro Tech Direct Current High Voltage Other Electrical Testers are high-frequency voltage doubling circuit, advanced PWM high-frequency pulse width modulation technology, closed-loop adjustment and large voltage feedback, greatly improving voltage stability. Use high-power IGBT devices and driving technology with superior performance and take special shielding, isolation and grounding measures according to electromagnetic compatibility theory. The DC high-voltage generator has achieved high quality, portability and can withstand rated voltage discharge without damage. They have the characteristics of large output power and small size, with reliable overvoltage.
Technical Specifications
| Rated Voltage | 60 kV |
| Rated Current | 2 mA |
| Rated Power | 120 W |
| Double Cylinder Height | 17.32 in (440 mm) |
| Output Voltage Accuracy | ± (1.0% Reading ± 2 words) |
| Output Current Accuracy | ± (1.0% Reading ± 2 words) |
| Ripple Coefficient | ≤0.5% |
| Way Of Working | Intermittent use, rated load 30 minutes |
| Overload Capability | No-load voltage can exceed 10% of rated voltage for 10 minutes. The maximum charging current is 1.25 times the rated current power supply AC 220 V ± 10% 50 Hz. |
| Working Environment | Temperature 14 ℉ to 104 ℉ (-10 ℃ to 40 ℃) |
| Machine Volume | 18.30 in x 15.35 in x 7.48 in (465 mm x 390 mm x 190 mm) |
| Weight | 19.84 lb (9 Kg) |
