Overview
Hospitality Enviro Tech Digital Vibration Meter is used for measuring periodic motion, to detect mechanical movement imbalances and misaligned. Designed for on-site measuring various mechanical vibration designs for quality control, run time and maintenance of equipment to provide data. It has a selection of high-performance accelerometers, to achieve accurate, repeatable measurements. It has the bearing condition measurement function.
Features
- In accordance with ISO 2372, used for periodic measurements, to detect out-of-balance, misalignment and other mechanical faults in rotating machines
- Specially designed for easy on-site vibration measurement of all rotating machinery for quality control, commissioning, and predictive maintenance purposes
- Individual high-quality accelerometer for accurate and repeatable measurements.
- Bearing condition monitoring function
- LCD digital display
- Lightweight and easy to use
- Wide frequency range (10Hz. to 10kHz.) in acceleration mode
- Automatic power shut off to conserve power
- Can communicate with PC computer for statistics and printing by the optional cable and the software for RS232C interface
Technical Specifications
| Acceleration | 0.33 ft/s2 to 655.8 ft/s2 (0.1 m/s2 to 199.9 m/s2) [10Hz to 1KHz and 10Hz to 10KHz] |
| Velocity | 0.0039 in to 7.87 in/s (0.1 mm/s to 199.9 mm/s) [10Hz to 1KHz] |
| Displacement | 0.000039 in to 0.079 in (0.001 mm to 1.999 mm) [10Hz to 1KHz] |
| Accuracy | < 5% |
| Operating Conditions | Temperature: 32℉ to 104℉ (0 ℃ to 40 ℃) |
| Humidity: ≤ 90% RH | |
| Power Supply | 4 AA 1.5V (UM-3) battery |
| Battery Indicator | Low battery indicator |
| Dimensions | 2.68 in x 1.62 in x 6.3 in (160 mm x 68 mm x 32 mm) |
| Weight | 0.4 lbs (181 g) |
