Features
- Designed for on-site vibration measurement of rotating machinery
- High-quality accelerometer for accurate and repeatable measurements
- Wide frequency range (10 Hz to 10 kHz) in acceleration
- Optional headphones for electronic stethoscope use
- Bearing condition monitoring function
- Bluetooth data output option
Technical Specifications
| Sensor | Piezoelectric Transducer |
| Measuring Range | Velocity 0.01 mm/s to 400 mm/s True RMS Displacement 0.000039 in to 0.157 in (0.001 mm to 4.0 mm) |
| Frequency Range | Acceleration 10 Hz to 10 kHz Velocity 10 Hz to 1 kHz Displacement 10 Hz to 1 kHz |
| Accuracy | 5% of Reading + 2 digits |
| Operating Conditions | 14 °F to 122 °F (0 °C to 50 °C) |
| Power Supply | 4 x 1.5 V AAA(UM-4) Battery |
| Optional Accessories | RS-232C Data Cable with Software Bluetooth Data Adapter with Software |
