Overview
Hospitality Enviro Tech digital thickness meter method, can be non destructively measuring magnetic metal matrix ( such as: steel, iron, nickel ) on non magnetic coatings thickness ( such as: galvanized, chrome, paint, electrophoresis, enamel, rubber, powder coating, enamel, etc.)
Features
- Fine small integrated and convenient to carry
- Metal probe, simple operation, and quick test speed
- A continuous test and a single measuring method
- Four statistical functions
- Can store 800 measurement data
- The instrument can be connected computers
- Zero calibration and two point calibration
- Operation process has the buzz sound prompt
- Automatic recognition of Fe and NFe substrates
- Low voltage indication
- Metallic test head and wear resistance
- Manual / automatic shutdown function
Technical Specifications
| Measuring Range | 0 to 1250 um |
| Using Environment | 32°F to 122°F (0℃ to 50℃) Relative humidity: 20%RH to 90%RH |
| The Thinnest Matrix | 0.15 in (0.4 mm) |
| Measurement Accuracy | ± (1% to 3%) + 1.5 um |
| Resolution Ratio | 0.1 um / 1 um |
| Minimum Matrix | 0.3 in x 0.3 in (10 mm x 10 mm) |
| Power Source | Three alkaline batteries ( no.7) |
| Size | 5.1 in x 2.7 in x 0.9 in (130 mm x 70 mm x 24 mm) |
| Weight | 0.22 lb (100 g) |
