Features
- 4CH oscilloscope + EXT + DVM + auto range function
- Over 32 types of auto-measurement function
- Advanced digital trigger system, high trigger sensitivity
- Support a variety of SCPI remote control command
- Support optional RS232 port and LAN port
- Stable and reliable quality, sturdy and durable
Technical Specification
| Display | 7 in (17.78 cm) |
| Display Resolution | 800 pixels x 480 pixels |
| Power Consumption | <30 W |
| Time Range | 8 ns to 10 s |
| Resolution | 8 ns |
| Baud Rate | 300 bit/s to 334000 bit/s |
| Data Index | 0 to 7 |
| Frequency | 1 kHz |
| Relative Humidity | ≤+104° F (≤ +40° C): ≤90% 106° F to 122° F (+41° C to 50° C): ≤60% |
| Operating Temperature | 32° F to 122° F (0 ℃ to 50 ℃) |
| Storage Temperature | -40° F to 159.8° F (-40 ℃ to 71 ℃) |
| Size | 12.51 in x 4.33 in x 5.90 in (318 mm x 110 mm x 150 mm) |
| Weight | 8.59 lb (3900 g) |
