Features
- Large screen (128 × 64 dot matrix LCD)
- Showing all functions and parameters
- Test at any angle, even upside down
- Support “forged steel (Steel)” material
- When using the D or DC impact device test “forged” sample
- Can read HB value directly, without the need for manual checking table
- Wide measuring range
- It can measure the hardness of all metallic materials
- Direct display of hardness scales HRB, HRC, HRA, HV, HB, HS, HL
- Three types of strength values immediately
- Seven impact devices are available for special application
- Automatically identify the type of impact devices
- Large capacity memory could store 600 groups
- (Relative to average times 32 to 1)
- Information including single measured value, mean value
- Testing data, impact direction, impact times, material, hardness scale
- Upper and lower limit can be preset
- It will alarm automatically when the result value exceeds the limit.
- Battery indicates the rest capacity of the battery and the charge status
- User calibration function
- USB port with the PC humanity multi-functions data proceeding software
- It can save data permanently
- NI-MH rechargeable battery as the power source
- Charge circuit integrated inside
Technical specification
| Impact Direction | Up, down, horizontal, slanting up, slanting down |
| Hardness Scales | HL, HB, HRB, HRC, HRA, HV, HS |
| Memory | 600 groups max |
| Work Voltage | 9 V or 500 mA |
| Continuous working period | 200 hrs |
| Weight | 21.1 oz (600 g) (host) |
| Dimensions | 8.2 in x 3.3 in x 1.7 in (210 mm x 85 mm x 45 mm) |
