Technical Specifications
| Storage Depth | 3.28 (1 m) sample point (single channel) |
| Bandwidth | 50 MHz |
| Minimum Pulse Width Digital Channels | 10 ns |
| The Highest Real-Time Sampling Rate | Analog channel: 1 GSa/s (channel>, 500 msa/s dual channel, 250 msa/s (3/4 channels) Digital channels: 1 GSa/s (8 channels), 50 omsa/s (16 channels) |
| The Highest Rate Of Waveform Capture | 30000 wfms/s |
| Standard Probe | 150 MHz RP 2200 passive agent pointed |
| High Resolution | The highest 12 bit |
| Input Coupling | AC, DC, GND |
| Input Impedance | Die form: (1 MO ± 15) ll (15 pf ± 3 pf); digital (100 k 0 ± 1%) ll (Bpf ± 3 pf) |
| Attenuation Coefficient Of The Probe | Analog channel: 0.01x to 1000x 1 to 2 to 5 |
| Input Voltage | Analog channel: 1300 Vrms, 100 Vrms, the transient over voltage 1000 Vpk use RP 2200 10:1 the loss of elbow; 300 Vrms digital channels: 40 Vrms transient love Vpk 800 |
| Interpolation | Sinx (x) or x interpolation (optional) |
| Dimensions | 12.32 in x 6.33 in x 4.81 in (313.1 mm x 160.8 mm x 122.4 mm) |
| Package Weight | 13.22 Ib (6 Kg) |
