Technical Specification
| Bandwidth | DC: 0 MHz to 10 MHz |
| Sample Rate | 100 MS/s |
| Interpolation | (Sinx)/x |
| Scanning Speed | 0.05 us/DIV to 0.1 s/DIV, step by 1 to 2 to 5 |
| Relay Time Accuracy | ±100 ppm |
| Trimming Ratio | 2.5: 1 |
| Max. Input Voltage | 400 V |
| Sample Rate | ±100 ppm |
| Ext. Trigger Input Impedance | 1 MΩ ±2%, in parallel with 20 pF ± 5 pF |
| Output Voltage | 0.5 Vpp ±2% |
| Frequency | 1 kHz (±1%) |
| Display | 3.7 in (9.39 cm) |
| Power Supply | 100 V to 240 V AC |
| Power Consumption | <15 W |
| Size | 4.60 in x 7.55 in x 11.33 in (117 mm x 192 mm x 288 mm) |
| Weight | 3.96 lb (1.8 kg) |
