Technical specification
| Channels | 2 |
| Bandwidth | 100 MHz |
| Sample Rate | 1 GS or s |
| Rise Time | ≤3.5 ns |
| Memory Depth | 10 K |
| Vertical Sensitivity (V or div) | 5 mV or div to 5 V or div (at input) |
| Vertical accuracy (A or D) | 8bits |
| Power | 100 V AC to 240 V AC, 50 Hz or 60 Hz CAT: II |
| Display | 7 in (17.7 cm) 65535 Color TFT LCD, 800 × 480 |
| Product Color | White + grey |
| Standard Accessories | Probes, Power Cord, USB Cable, PC Software CD |
| Product Size (W × H × D) | 11.8 in x 5.9 in x 2.7 in (301 mm × 152 mm × 70 mm) |
| Product Net Weight | 2.4 lb (1.1 kg) |
