Technical Specifications
| Sensor | Piezoelectric Sensor |
| Measuring Range | Acceleration 0.01 m/s2 to 200 m/s2 Equivalent Peak Velocity 0.01 m/s to 200 m/s True RMS Displacement 0.000039 in to 0.079 in (0.001 mm to 2.0 mm) Equivalent Peak-Peak |
| Frequency Range | Acceleration 10 Hz to 1 kHz, 10 Hz to 10 kHz Velocity 10 Hz to 1 kHz Displacement 10 Hz to 1 kHz |
| Accuracy | <5% |
| Operation Conditions | Temperature 14 °F to 122 °F (0 °C to 50 °C) Humidity <90% RH |
| Power Supply | 2 AA 1.5 V (UM-3) battery |
| Dimensions | 5.39 in x 2.99 in x 1.26 in (137 mm x 76 mm x 32 mm) |
| Weight | 0.94 lb (425 g) |
